MATLAB拟合微分方程组

如何用数据拟合volterra模型参数和初值（如何拟合微分方程组）（MATLAB）

已知x,y,t的数据拟合abcdxoyo

参考一下这个代码，不一定对哈：

function dydt = volterra(t,y,a,b,c)
x = y(1);
y = y(2);
dxdt = x*(a-b*y);
dydt = y*(-c+dx);
dydt = [dxdt; dydt];
end

tspan = [0 10];
y0 = [1;1];
a = 2;
b = 1;
c = 3;
[t,y] = ode45(@(t,y) volterra(t,y,a,b,c), tspan, y0);

• 这篇博客: 【数学建模】基于matlab GUI弱肉强食问题—Volterra 模型【含Matlab源码 1502期】中的 二、部分源代码 部分也许能够解决你的问题, 你可以仔细阅读以下内容或跳转源博客中阅读:


• function varargout = main(varargin)
  % MAIN MATLAB code for main.fig
  %      MAIN, by itself, creates a new MAIN or raises the existing
  %      singleton*.
  %
  %      H = MAIN returns the handle to a new MAIN or the handle to
  %      the existing singleton*.
  %
  %      MAIN('CALLBACK',hObject,eventData,handles,...) calls the local
  %      function named CALLBACK in MAIN.M with the given input arguments.
  %
  %      MAIN('Property','Value',...) creates a new MAIN or raises the
  %      existing singleton*.  Starting from the left, property value pairs are
  %      applied to the GUI before main_OpeningFcn gets called.  An
  %      unrecognized property name or invalid value makes property application
  %      stop.  All inputs are passed to main_OpeningFcn via varargin.
  %
  %      *See GUI Options on GUIDE's Tools menu.  Choose "GUI allows only one
  %      instance to run (singleton)".
  %
  % See also: GUIDE, GUIDATA, GUIHANDLES

  % Edit the above text to modify the response to help main

  % Last Modified by GUIDE v2.5 27-Oct-2021 15:55:05

  % Begin initialization code - DO NOT EDIT
  gui_Singleton = 1;
  gui_State = struct('gui_Name',       mfilename, ...
                     'gui_Singleton',  gui_Singleton, ...
                     'gui_OpeningFcn', @main_OpeningFcn, ...
                     'gui_OutputFcn',  @main_OutputFcn, ...
                     'gui_LayoutFcn',  [] , ...
                     'gui_Callback',   []);
  if nargin && ischar(varargin{1})
      gui_State.gui_Callback = str2func(varargin{1});
  end

  if nargout
      [varargout{1:nargout}] = gui_mainfcn(gui_State, varargin{:});
  else
      gui_mainfcn(gui_State, varargin{:});
  end
  % End initialization code - DO NOT EDIT


  % --- Executes just before main is made visible.
  function main_OpeningFcn(hObject, ~, handles, varargin)
  % This function has no output args, see OutputFcn.
  % hObject    handle to figure
  % eventdata  reserved - to be defined in a future version of MATLAB
  % handles    structure with handles and user data (see GUIDATA)
  % varargin   command line arguments to main (see VARARGIN)

  % Choose default command line output for main
  handles.output = hObject;

  % Update handles structure
  guidata(hObject, handles);

  % UIWAIT makes main wait for user response (see UIRESUME)
  % uiwait(handles.figure1);

  % ha = axes('units','normalized','pos',[0 0 1 1]);
  % uistack(ha,'down');
  % img = imread('ly.jpg');
  % image(img);
  % colormap gray
  % set(ha,'handlevisibility','off','visible','off');
  % axis off

  %建立对话框标题
  set(handles.figure1, 'name', '模型仿真系统参数设定&模式选择');
  %set(handles.figure1, 'color', [0, 200, 100]/255);
  set(handles.figure1, 'units', 'normalized');
  set(handles.figure1, 'position', [0.2, 0.2, 0.6, 0.6]);

  % --- Outputs from this function are returned to the command line.
  function varargout = main_OutputFcn(hObject, eventdata, handles)
  % varargout  cell array for returning output args (see VARARGOUT);
  % hObject    handle to figure
  % eventdata  reserved - to be defined in a future version of MATLAB
  % handles    structure with handles and user data (see GUIDATA)

  % Get default command line output from handles structure
  varargout{1} = handles.output;



  function x1_0_Callback(hObject, eventdata, handles)
  % hObject    handle to x1_0 (see GCBO)
  % eventdata  reserved - to be defined in a future version of MATLAB
  % handles    structure with handles and user data (see GUIDATA)

  % Hints: get(hObject,'String') returns contents of x1_0 as text
  %        str2double(get(hObject,'String')) returns contents of x1_0 as a double


  % --- Executes during object creation, after setting all properties.
  function x1_0_CreateFcn(hObject, eventdata, handles)
  % hObject    handle to x1_0 (see GCBO)
  % eventdata  reserved - to be defined in a future version of MATLAB
  % handles    empty - handles not created until after all CreateFcns called

  % Hint: edit controls usually have a white background on Windows.
  %       See ISPC and COMPUTER.
  if ispc && isequal(get(hObject,'BackgroundColor'), get(0,'defaultUicontrolBackgroundColor'))
      set(hObject,'BackgroundColor','white');
  end



  function x2_0_Callback(hObject, eventdata, handles)
  % hObject    handle to x2_0 (see GCBO)
  % eventdata  reserved - to be defined in a future version of MATLAB
  % handles    structure with handles and user data (see GUIDATA)

  % Hints: get(hObject,'String') returns contents of x2_0 as text
  %        str2double(get(hObject,'String')) returns contents of x2_0 as a double


  % --- Executes during object creation, after setting all properties.
  function x2_0_CreateFcn(hObject, eventdata, handles)
  % hObject    handle to x2_0 (see GCBO)
  % eventdata  reserved - to be defined in a future version of MATLAB
  % handles    empty - handles not created until after all CreateFcns called

  % Hint: edit controls usually have a white background on Windows.
  %       See ISPC and COMPUTER.
  if ispc && isequal(get(hObject,'BackgroundColor'), get(0,'defaultUicontrolBackgroundColor'))
      set(hObject,'BackgroundColor','white');
  end



  function l1_Callback(hObject, eventdata, handles)
  % hObject    handle to l1 (see GCBO)
  % eventdata  reserved - to be defined in a future version of MATLAB
  % handles    structure with handles and user data (see GUIDATA)

  % Hints: get(hObject,'String') returns contents of l1 as text
  %        str2double(get(hObject,'String')) returns contents of l1 as a double


  % --- Executes during object creation, after setting all properties.
  function l1_CreateFcn(hObject, eventdata, handles)
  % hObject    handle to l1 (see GCBO)
  % eventdata  reserved - to be defined in a future version of MATLAB
  % handles    empty - handles not created until after all CreateFcns called

  % Hint: edit controls usually have a white background on Windows.
  %       See ISPC and COMPUTER.
  if ispc && isequal(get(hObject,'BackgroundColor'), get(0,'defaultUicontrolBackgroundColor'))
      set(hObject,'BackgroundColor','white');
  end



  function r1_Callback(hObject, eventdata, handles)
  % hObject    handle to r1 (see GCBO)
  % eventdata  reserved - to be defined in a future version of MATLAB
  % handles    structure with handles and user data (see GUIDATA)

  % Hints: get(hObject,'String') returns contents of r1 as text
  %        str2double(get(hObject,'String')) returns contents of r1 as a double


  % --- Executes during object creation, after setting all properties.
  function r1_CreateFcn(hObject, eventdata, handles)
  % hObject    handle to r1 (see GCBO)
  % eventdata  reserved - to be defined in a future version of MATLAB
  % handles    empty - handles not created until after all CreateFcns called

  % Hint: edit controls usually have a white background on Windows.
  %       See ISPC and COMPUTER.
  if ispc && isequal(get(hObject,'BackgroundColor'), get(0,'defaultUicontrolBackgroundColor'))
      set(hObject,'BackgroundColor','white');
  end



  function r2_Callback(hObject, eventdata, handles)
  % hObject    handle to r2 (see GCBO)
  % eventdata  reserved - to be defined in a future version of MATLAB
  % handles    structure with handles and user data (see GUIDATA)

  % Hints: get(hObject,'String') returns contents of r2 as text
  %        str2double(get(hObject,'String')) returns contents of r2 as a double


  % --- Executes during object creation, after setting all properties.
  function r2_CreateFcn(hObject, eventdata, handles)
  % hObject    handle to r2 (see GCBO)
  % eventdata  reserved - to be defined in a future version of MATLAB
  % handles    empty - handles not created until after all CreateFcns called

  % Hint: edit controls usually have a white background on Windows.
  %       See ISPC and COMPUTER.
  if ispc && isequal(get(hObject,'BackgroundColor'), get(0,'defaultUicontrolBackgroundColor'))
      set(hObject,'BackgroundColor','white');
  end



  function l2_Callback(hObject, eventdata, handles)
  % hObject    handle to l2 (see GCBO)
  % eventdata  reserved - to be defined in a future version of MATLAB
  % handles    structure with handles and user data (see GUIDATA)

  % Hints: get(hObject,'String') returns contents of l2 as text
  %        str2double(get(hObject,'String')) returns contents of l2 as a double


  % --- Executes during object creation, after setting all properties.
  function l2_CreateFcn(hObject, eventdata, handles)
  % hObject    handle to l2 (see GCBO)
  % eventdata  reserved - to be defined in a future version of MATLAB
  % handles    empty - handles not created until after all CreateFcns called

  % Hint: edit controls usually have a white background on Windows.
  %       See ISPC and COMPUTER.
  if ispc && isequal(get(hObject,'BackgroundColor'), get(0,'defaultUicontrolBackgroundColor'))
      set(hObject,'BackgroundColor','white');
  end
